Fanless Multimedia PC – Dual 4K Visuals & Industrial Reliability

Intelli TWL01 Edge

The Intelli TWL01 Edge is a compact, fanless industrial system built for high-definition multimedia applications and efficient edge computing. Powered by the Intel® Core™ Processor N-series (formerly Twin Lake), it delivers the perfect balance of performance and power efficiency for 24/7 operations. With dual HDMI 2.0b ports supporting simultaneous 4K displays, it is the ideal engine for interactive kiosks, digital signage, and smart retail analytics.



Designed for seamless integration, the system features a rugged, fanless chassis and support for Windows 11 LTSC and Ubuntu 24.04 LTS. Its versatile I/O, including 2.5GbE LAN, four USB 3.2 Gen 2 ports, and a wide 9V–36V power input, ensures reliability in diverse commercial and industrial environments. Whether you are deploying smart vending machines or real-time monitoring dashboards, the Intelli TWL01 Edge provides a stable, long-life hardware foundation.

Order Now
Download Datasheet

Overview　|　System Details　|　Community Support

Key Strengths

Intel Inside processor badge

Efficient Performance

  • Powered by the Intel® Processor N-series (Core™ 3 N355 / N250/ N150 / N97), featuring an 8-core/8-thread architecture optimized for low-power multitasking.
  • Equipped with up to 16GB LPDDR5 memory and 64GB onboard eMMC (optional up to 128GB) for snappy system responsiveness and reliable data storage.
  • Ideal for entry-to-mid-level AI workloads, interactive HMI, and edge data processing.
Dual 4K display (1)

Brilliant Dual 4K Displays

  • Dual HDMI 2.0b ports support two independent 4K displays, enabling rich visual storytelling and data-heavy dashboards.
  • Integrated Intel® UHD Graphics with DirectX 12.1 support ensures smooth video playback and efficient rendering for high-resolution multimedia content.
  • Hardware-Accelerated Codecs: Built-in support for AV1, HEVC (H.265), VP9, and AVC (H.264) hardware decoding and encoding.
expand

Flexible Connectivity & Expansion

  • High-speed peripheral integration via four USB 3.2 Gen 2 (10Gbps) ports and a dedicated COM port (RS-232/422/485).
  • Expansion-ready with M.2 2280 M-Key for NVMe SSD storage and M.2 2230 E-Key for Wi-Fi/Bluetooth modules.
  • Dual Gigabit Ethernet (RJ-45) ensures seamless networking and connectivity.
fanless

Industrial & Fanless Design

  • Fanless and silent operation reduces dust accumulation and mechanical failure, making it perfect for sensitive or harsh environments.
  • Ruggedized build with a wide 9V to 36V DC input and vibration-resistant soldered memory for maximum uptime.
  • Ultra-compact form factor (W x H x D:152mm x 124mm x 39mm) allows for discreet installation behind screens or inside slim enclosures.
Security and Connectivity Icon

Enterprise Ready & Secure

  • Built-in TPM 2.0 for hardware-based security, protecting your edge data and ensuring device integrity.
  • Supports DIN Rail, VESA, and Wallmount options, providing the flexibility needed for rapid field deployment.
  • Backed by AAEON’s industrial longevity and software support for Yocto 5.1, Ubuntu, and Windows.

Vertical Markets

Smart Retail & Self-Service Kiosks
  • Interactive vending machines and payment terminals
  • AI-driven digital signage with audience analytics
Digital Signage & Information Displays
  • Public transit flight/train information systems
  •  Multi-screen menu boards and advertising walls
Industrial HMI & Control
  • Machine-level visualization and status monitoring
Smart City & Public Safety
  • Entry-level traffic flow monitoring and IoT gateways.
  • Perimeter surveillance and automated access logs.

Block Diagram

UP Squared Pro Block Diagram

Community Support

UP Community

Join our developer community and share your knowledge about UP. Stuck with your project? Get help from one of the hundreds of industry professions that are already using UP!

UP Wiki

Learn more about UP with code and project examples, tutorials and OS installation guides

Find out the pinout and its pin-function here.

UP Downloads

Download everything you need to start your project. Our download area includes drivers, OS image, 2D/3D drawings, environment test reports, certifications and more.
