Accelerate AI on the Edge

UP Squared Pro 710H

The UP Squared Pro 710H Edge combines the edge AI functionality of the Hailo-8™ edge AI processor with the power-efficient operation of the Intel® Processor N-series, providing a streamlined deployment platform for a range of versatile market solutions.

Optimized connectivity options, multiple display outputs, and wireless expansion offer multifaceted interface configurations with which to curate project-driven applications, while purpose-built drivers grant access to Hailo’s software suites for Ubuntu and Windows to facilitate development, all in one place.

Overview　|　Specifications　|　Community Support

Key Strengths

Integrated AI Acceleration

With its integrated Hailo-8™ edge AI processor, the UP Squared Pro 710H Edge provides a shortcut to machine learning frameworks and pre-trained models through a comprehensive AI software suite. Coupled with a choice of either the Intel® Core™ i3-N305 or Intel® Processor N97 CPU, the UP Squared Pro 710H Edge maintains exceptional power-efficiency, even when handling complex tasks such as AI inferencing, data analytics, and multimedia processing.

Peripheral Synchronization

The UP Squared Pro 710H Edge brings unmatched peripheral support to a compact, mountable fanless PC, with dual 2.5GbE, dual COM, and dual USB ports, along with a 40-pin GPIO to facilitate the installation of cameras, sensors, and industrial communication protocols. Alongside a broad 12V ~ 36V power input range and multiple mounting options, the UP Squared Pro 710H Edge represents an ideal platform with which to build identity management, AMR, and smart advertising devices.

Streamlined Expansion

Conveniently grouped bottom-side expansion slots grant users access to Wi-Fi, 4G/5G, and additional storage, optimizing the device’s connectivity for low-latency edge-to-cloud communication. Additionally, this expansion provides the opportunity to scale the AI performance of the system, combining the 26 TOPS of its Hailo-8™ edge AI processor with additional AI acceleration cards.

AI Assisted Integrated Advertising Turns Passerby into Customers

A company took on the task of using AI to optimize digital out-of-home (DOOH) advertising for shopping malls and department stores. With the aim of analyzing customer behaviors and preferences in order to craft in-store marketing displays in real-time, the company turned to the new UP Squared Pro 710H Edge.

WordPress › Error

There has been a critical error on this website.

Learn more about troubleshooting WordPress.

System
CPU	Intel® Core™ i3-N305 (8C, 1.80 GHz, 15W) Intel® Processor N97 (4C, 2.00 GHz, 12W) Onboard Hailo-8™ edge AI processor
Graphics	Intel® UHD Graphics for 12th Gen Intel® Processors
Memory	Up to 16GB onboard LPDDR5
Storage	Up to 128GB onboard eMMC
I/O	HDMI 2.0b x 1 DP 1.2 x 1 RS-232/422/485 from 10 pin header x 2
Camera	MIPI-CSI via 61-Pin FPC Connector x 1
USB	USB 2.0 x 2 (from 10 pin header x 1) USB 3.2 Gen 2 (Type-A) x 2
Expansion	40-pin GPIO x 1 M.2 2230 E-Key x 1 (CNVI, PCIe Gen 3 [x1], USB 2.0) M.2 2280 M-Key x 1 (PCIe Gen 3 [x2], colay with M.2 3052 B-Key x 1) M.2 3052 B-Key x 1 (USB 3.2 Gen 2 only) (Optional)
Display Interface	HDMI 2.0b x 1 DP 1.2 x 1
Ethernet	2.5GbE x 2 (Intel® Ethernet Controller I226-IT)
Security	Onboard TPM 2.0
RTC	Yes
OS support	Windows 10 IoT Enterprise Ubuntu 22.04 LTS Yocto 4.0
Power Requirement
Power	12V-36V DC-in Phoenix connector (Optional: Lockable plug)
Power Supply Type	AT/ATX
Power Consumption (Typical)	50W~55W
Mechanical
Dimension	101.6mm x 101.6mm (4″ x 4″)
Net Weight	0.20kg (0.44 lbs)
Gross Weight	0.35kg (0.77 lbs)
Environment
Operating Temperature	0°C ~ 60°C (32°F ~ 140°F), 0.5m/s airflow
Operating Humidity	0% ~ 90% relative humidity, non-condensing
MTBF	422,053 Hours
Certification	CE/FCC Class A, RoHS Compliant, REACH

System
CPU	Intel® Core™ i3-N305 (8C, 1.80 GHz, 15W) Intel® Processor N97 (4C, 2.00 GHz, 12W) Onboard Hailo-8™ edge AI processor
Memory	Up to 16GB onboard LPDDR5
Graphics	Intel® UHD Graphics for 12th Gen Intel® Processors
Storage	Up to 128GB onboard eMMC
Ethernet	2.5GbE x 2 (Intel® I226-IT)
WIFI/BT	Optional with M.2 2230 E-key x 1
Expansion Slot	M.2 2230 E-Key x 1 (CNVI, PCIe Gen 3 [x1], USB 2.0) M.2 2280 M-Key x 1 (PCIe Gen 3 [x2]), Optional: M.2 3052 B-Key with Nano SIM slot (USB 3.0)
Security	Onboard TPM 2.0
OS Support	Windows® 10 IoT Enterprise Ubuntu 22.04 LTS
I/O Placements
USB	USB 3.2 Gen 2 x 2 (Type-A)
Display Port	HDMI 2.0b x 1 DP 1.2 x 1
Ethernet	2.5GbE x 2 (Intel® I226-IT)
COM	RS-232/422/485 x 2
Audio	—
GPIO	40-pin GPIO x 1
Power Supply
Power requirement	12V-36V DC-in Phoenix connector (Optional: Lockable plug)
Power supply type	AT/ATX (AT as default)
Power Consumption(Typical)	50W~55W
Mechanical
Mounting	VESA Mount/Wall Mount/DIN RAIL (Optional)
Dimensions (WxHxD)	134mm x 105mm x 60mm (5.28” x 4.13” x 2.36”)
Net Weight	0.69kg (1.8 lbs)
Gross Weight	0.97kg (2.2 lbs)
Environment
Operating Temperature	32°F ~ 140°F (0°C ~ 60°C) / 0.5 airflow
Operating Humidity	0% ~ 90% relative humidity, non-condensing
Storage Temperature	-4°F ~ 158°F (-20°C ~ 70°C)
MTBF	422,053 Hours
Certification	CE/FCC Class A, RoHS Compliant, REACH
